I. Core Specifications

Model: 15694-65992 (Replaces 15694-65990)

Voltage: DC 12V

Function: Glow Plug Delay Control + Dashboard Indicator Light

Delay Duration: Approx. 6–12 seconds (Automatically adjusts based on ambient temperature)

Terminals: 5-Pin (4 Main + 1 Mounting), Direct Plug-in (Plastic Housing)

Housing: Black flame-retardant plastic housing with mounting tabs; vibration-resistant

Weight: Approx. 0.14 kg

II. Compatible Models (Full Range of Kubota Small/Medium-Displacement Diesel Engines)

Engines: D722, D902, D1005, D1105, D1305, D1703, V2203, V2403, V2607, V3300, V3600, etc.

Equipment: KX Series Excavators, KH Series Skid Steer Loaders, B/L Series Tractors, 788/888 Series Harvesters

III. Differences from Model 5H492-41350 (Same Manufacturer, Different Model Variants)

15694-65992: 5-Pin configuration; Manufactured by NGK; Includes dashboard indicator light control; Features more precise delay timing; Commonly used in excavators and tractors.

5H492-41350: 4-Pin configuration; Manufactured by Denso; Pure glow plug preheating function (no indicator light control); Simple structural design; Commonly used in harvesters.
