213-0772 Caterpillar (CAT) 24V Magnetic Switch Assembly (Solenoid Switch)—primarily used for engine starting control, and widely compatible with Caterpillar excavators, loaders, and various engine series. I. Core Specifications

OEM Model: 213-0772 (2130772)

Type: Starter Solenoid Switch (Magnetic Switch)

Voltage: DC 24V

Operating Temperature: -40°F to 185°F (-40°C to 85°C)

Dimensions: Length 7.1 cm × Width 4.3 cm × Height 9.4 cm

Connector: 2-Pin Electrical Connector

Function: Controls the opening and closing of the starter motor circuit to initiate engine ignition

II. Compatible Models (Core)

1. Excavators (Primary)

Small: 308D, 311D LRR, 311F LRR, 312C/L, 312D/L, 312D2, 313D, 314E CR/LCR, 315C/D L, 316E L, 318C/D L, 319C/D L

Medium: 320C/D, 323D, 324D, 325C/D, 329D, 330C/D, 336D, 345C/D, 349D, 385C

Wheeled: M325C MH, W345C MH

2. Engine Series (Full Coverage)

C4.4, C7, C7.1, C9, C9.3, C13, C15, C18

3066, 3126, 3126B, 3176C, 3196, 3406E, 3456

3. Other Equipment

Wheel Loaders: 950G, 962G, 966G, 972G, 980G/H, 988G/H

Dozers: D6N, D6R, D7R, D8R, D9R

III. Replacement Models AEP16024C02 (Direct Replacement)

213-0772-01 (Upgraded Model in the Same Series)
