Name:18000 lbs 4x4 Winch

Product Description

18000 lbs 4x4 Winch

•  Rated line: 18000lbs(6818kgs)
•  Motor: 5.6kw,7.5hp, 12V DC Series Wound
•  Control: Remote switch 29.8ft(9.1m)lead
•  Geartrain: 3 Stage planetary
•  Gear reduction: 337:1
•  Braking Action: Automatic in-The Drum
•  Drum size: Diameter 4"(101.6mm)Length 10"(254mm)
•  Fairlead : 4-Way Roller Fairlead
•  Remote Control: Include
•  NW: 76 kgs
•  Overall dimensions: (L×W×H )(682.8×214×253.6mm)
•  Mounting Bolt Pattern: 12.00±0.015"×6.50±0.010"(304 8x165mm)
