4000 lbs Electric ATV UTV Winches

• Rated line: 4000lbs.(1818kgs.)single-line

• Motor: 1.3hp,12V DC Permanent Magnet

• Control: Handlebar mounted Mini-rocker switch

• Gear train: 3-Stage planetary

• Gear ratio: 166:1

• Clutch(freespooling): Cam activated

• Brake:Dynamic: Mechanical brake is available

• Drum Diameter/Length: 2.0"/2.9"

• Wire rope: 6.0mm×12.2m

• Recommended Battary: 12Amp/hour minimum for winching

• Battery Leads: 6 gauge

• Dimensions: L×W×H(324×117×117.5)

• NW/GW: 29KG/31KG(2pcs)
