3000 lbs 12V DC Electric Winches for ATV UTV

• Rated line pull: 3000lbs( 1361 kgs)

• Motor :0.9kw, 1.2hp , 12V DC Permanent Magent

• Gearing: Differential planetary

• Gear ratio: 153:1

• Freespooling clutch: Pull and trun

• Braking Action: Dynamic

• Wire rope: 7/36"×30'(5.5mmx9.2m)

• Dimensions: L×W×H (297×105×105mm)

• Drum Diameter: 1.25"(31.75mm)

• Drum Length: 2 9" (74mm)

• NW/GW: 15KGS/17KGS(2pcs)

• Meas: 35×30×32cm (2pcs)
