| Name: | 1500 lbs Electric Winches for ATV UTV |
|---|---|
Product Description
1500 lbs Electric Winches for ATV UTV
Rated line pull: 1500lbs( 680 kgs)
Motor :0.6kw, 0.8hp , 12V DC Permanent Magent
Gearing: 3-Stage planetary
Gear ratio: 103:1
Freespooling clutch: Cam activated
Wire rope: 5/32"×40'(4mmx12.2m)
Dimensions: L×W×H (276×143×154)
Drum Diameter: 1.5"(38mm)
Drum Length: 3" (76mm)
NW: 9.8KG
Meas: 330*250*250 (1pc)
